Yidi IDI2304 Three-Phase Electrical Parameter Measuring Instrument IDI2308 Electrical Energy Comprehensive Measuring Instrument Safety Testing
The "Yidi IDI2304" and "IDI2308" you mentioned are high-performance three-phase electrical parameter and electrical energy comprehensive measuring instruments launched by Qingdao Yidi Electronics (IDI). Such devices are commonly used in industrial testing for performance evaluation of motors, frequency converters, power supplies, and various three-phase electrical appliances.
Based on your keywords, here is a summary of the core technical parameters, functional features, and positioning in safety testing applications of these two instruments:
1. Core Functions and Performance Features
High-Precision Measurement: Adopts 16-channel 12-bit ADC, with a maximum sampling rate of 1Msps, and measurement accuracy up to 0.5 class.
Comprehensive Multi-Parameter Measurement: Can simultaneously measure and display key parameters such as three-phase voltage, current, active power, electrical energy, power factor, frequency, and cumulative time.
Intelligent Alarm and Locking: Supports setting upper and lower limits for voltage, current, power, and electrical energy. When exceeded, triggers audible and visual alarms (digital tube flashing and buzzer alarm), facilitating rapid screening of non-conforming products on the production line.
Flexible Communication Networking: Optional RS232 or RS485 communication interfaces, and supports host computer software, facilitating remote transmission, traceability, and multi-point networking of test data.
2. Key Technical Indicators (Reference to IDI2504/2304 Series)
Voltage Measurement Range: 5.0V ~ 600.0V, resolution 0.1V.
Current Measurement Range: 0.020A ~ 40.00A (supports multi-range automatic or manual switching), resolution 0.001A.
Active Power Measurement Range: 2.0W ~ 24.00kW, accuracy is ±(measured value × 0.4% + range × 0.1%) when COSΦ≥0.5.
Electrical Energy Measurement Range: 0.0 ~ 9999.9MW.h.
Frequency Measurement Range: 40.0Hz ~ 500.0Hz, suitable for wide-frequency testing needs.
3. Clarification on "Safety Testing" Positioning
It should be clearly noted that IDI2304/IDI2308 are "electrical parameter and electrical energy measuring instruments," not direct "comprehensive safety testing instruments."
Role of Electrical Parameter Instruments: During safety testing or product certification (such as CCC, CE), they are mainly used for "input testing" (verifying whether the product's rated input power and current are within standard ranges), "standby power consumption testing," and data collection of power and electrical energy in "heating tests."
Comprehensive Safety Testing Instruments: If you need to perform safety performance tests such as withstand voltage (high voltage test), insulation resistance, ground resistance, and leakage current, you need to use Yidi's comprehensive safety testing instrument series (such as MN427X(P) series, IDI6121 series leakage current testers, etc.).
💡 Further Assistance
May I ask what your specific current needs are: Safety Testing Solution Configuration: If you are setting up a production line safety testing station, do you need me to sort out a complete equipment configuration list of "electrical parameter instrument + comprehensive safety testing instrument"?
Operation and Communication Debugging: Do you need to understand the wiring specifications, upper and lower limit alarm setting methods, or the communication protocol and data retrieval methods of the RS485 host computer software for this instrument?
Product Selection and Quotation: Do you need to confirm the specific differences between IDI2304 and IDI2308, or learn about the market reference prices and procurement channels for this series of three-phase measuring instruments?
